Description
| 1 | Voltage | V | 12.0 | 24.0 | 36.0 |
| 2 | Terminal resistance | Ω | 0.14 | 0.58 | 1.26 |
| 3 | No-load speed | rpm | 10400 | 10400 | 10400 |
| 4 | No-load current | A | 0.44 | 0.23 | 0.15 |
| 5 | Stall torque | mNm | 904 | 912 | 931 |
| 6 | Stall current | A | 83.3 | 41.7 | 28.6 |
| 7 | Nominal torque | mNm | 86.7 | 89.5 | 89.6 |
| 8 | Nominal speed | rpm | 7820 | 8040 | 8500 |
| 9 | Nominal current | A | 8.1 | 4.1 | 2.7 |
| 10 | Max. output power | W | 247 | 248 | 254 |
| 11 | Max. efficiency | % | 86.0 | 85.7 | 86.2 |
| 12 | Back-EMF constant | mV/rpm | 1.1 | 2.3 | 3.4 |
| 13 | Torque constant | mNm/A | 10.9 | 22.0 | 32.8 |
| 14 | KV Value | rpm/V | 871 | 433 | 290 |
| 15 | Speed/torque gradient | rpm/mNm | 11.6 | 11.4 | 11.2 |
| 16 | Rotor inertia | gcm² | 31 | 31 | 31 |
| 17 | Weight | g | 53 | 53 | 53 |
| 18 | Thermal resistance housing-ambient | K/W | – | 1.7 | – |
| 19 | Thermal resistance winding-housing | K/W | – | 1.8 | – |
| 20 | Thermal time constant motor | s | – | 300 | – |
| 21 | Thermal time constant winding | s | – | 43 | – |
| 22 | Operating temperature range | °C | – | -40~+120 | – |
| 23 | Thermal class of winding | °C | – | 180 | – |
| 24 | Axial play | mm | – | 0.014 | – |
| 25 | Radial play | mm | – | 0.008 | – |
| 26 | Axial load dynamic | N | – | 5 | – |
| 27 | Axial load static | N | – | 80 | – |
| 28 | Radial load at 3 mm from mounting face | N | – | 29 | – |
| 29 | No. of pole pairs | – | – | 7 | – |
| 30 | Bearings | – | – | 2 ball bearings | – |
| 31 | Commutation | – | – | Sensorless | – |
| 32 | Protection class | – | – | IP 20 | – |
