Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SG4508L05 | 5 | 4.3 to 5.4 | 0.08 | 0.4 | 3500 | 0.03 | 1.07 | 3.54 | 0.14 | 21.8 |
| SG4508M05 | 5 | 4.3 to 5.4 | 0.17 | 0.85 | 4500 | 0.04 | 1.35 | 7.0 | 0.28 | 23 |
| SG4508M12 | 12 | 7.0 to 13.5 | 0.07 | 0.84 | ||||||
| SG4508H12 | 12 | 7.0 to 13.5 | 0.09 | 1.08 | 5000 | 0.04 | 1.45 | 7.08 | 0.28 | 25 |
