Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SG5020L05 | 5 | 3.6 to 6.8 | 0.33 | 1.65 | 4000 | 0.15 | 5.21 | 9.61 | 0.38 | 27.0 |
| SG5020L12 | 12 | 7.0 to 13.5 | 0.14 | 1.68 | ||||||
| SG5020L24 | 24 | 18 to 26.5 | 0.07 | 1.68 | ||||||
| SG5020M05 | 5 | 3.6 to 6.8 | 0.39 | 1.95 | 5000 | 0.17 | 5.86 | 16.23 | 0.64 | 35.0 |
| SG5020M12 | 12 | 7.0 to 13.5 | 0.19 | 2.28 | ||||||
| SG5020M24 | 24 | 18 to 26.5 | 0.11 | 2.64 | ||||||
| SG5020H12 | 12 | 7.0 to 13.5 | 0.23 | 2.76 | 5500 | 0.18 | 6.12 | 17.73 | 0.70 | 37.4 |
| SG5020H24 | 24 | 18 to 26.5 | 0.15 | 3.6 | ||||||
