Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SG6015L05 | 5 | 3.6 to 6.8 | 0.15 | 0.75 | 3500 | 0.08 | 2.94 | 7.06 | 0.28 | 31.2 |
| SG6015L12 | 12 | 7.0 to 13.5 | 0.06 | 0.72 | ||||||
| SG6015M12 | 12 | 7.0 to 13.5 | 0.08 | 0.96 | 4000 | 0.09 | 3.19 | 9.33 | 0.37 | 35 |
| SG6015M24 | 24 | 18 to 26.5 | 0.04 | 0.96 | ||||||
| SG6015H12 | 12 | 7.0 to 13.5 | 0.11 | 1.32 | 4500 | 0.11 | 3.78 | 12.1 | 0.48 | 37.8 |
| SG6015H24 | 24 | 18 to 26.5 | 0.06 | 1.44 | ||||||
