Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SG6025L05 | 5 | 4.3 to 5.4 | 0.35 | 1.75 | 3500 | 0.24 | 8.36 | 11.11 | 0.44 | 34.7 |
| SG6025L12 | 12 | 7.0 to 13.5 | 0.16 | 1.92 | ||||||
| SG6025L24 | 24 | 18 to 26.5 | 0.08 | 1.92 | ||||||
| SG6025M05 | 5 | 4.3 to 5.4 | 0.50 | 2.50 | 4500 | 0.29 | 10.18 | 22.51 | 0.90 | 41.6 |
| SG6025M12 | 12 | 7.0 to 13.5 | 0.22 | 2.44 | ||||||
| SG6025M24 | 24 | 18 to 26.5 | 0.11 | 2.64 | ||||||
| SG6025H05 | 5 | 4.3 to 5.4 | 0.60 | 3.00 | 5000 | 0.31 | 10.88 | 26.4 | 1.04 | 44.4 |
| SG6025H12 | 12 | 7.0 to 13.5 | 0.26 | 3.12 | ||||||
| SG6025H24 | 24 | 18 to 26.5 | 0.13 | 3.12 | ||||||
