Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SG6028L05 | 05 | 3.6 to 6.8 | 0.08 | 0.40 | 2000 | 0.08 | 2.93 | 1.49 | 0.06 | 25.3 |
| SG6028L12 | 12 | 7.0 to 13.5 | 0.03 | 0.36 | ||||||
| SG6028L24 | 24 | 18 to 26.5 | 0.02 | 0.48 | ||||||
| SG6028M05 | 05 | 3.6 to 6.8 | 0.10 | 0.50 | 2500 | 0.09 | 3.3 | 2.6 | 0.10 | 26.6 |
| SG6028M12 | 12 | 7.0 to 13.5 | 0.04 | 0.48 | ||||||
| SG6028M24 | 24 | 18 to 26.5 | 0.02 | 0.48 | ||||||
| SG6028H05 | 05 | 3.6 to 6.8 | 0.12 | 0.60 | 3000 | 0.11 | 3.8 | 3.98 | 0.16 | 28.6 |
| SG6028H12 | 12 | 7.0 to 13.5 | 0.05 | 0.60 | ||||||
| SG6028H24 | 24 | 18 to 26.5 | 0.03 | 0.72 | ||||||
| SG6028H05-HH | 05 | 3.6 to 6.8 | 0.20 | 1.0 | 3500 | 0.13 | 4.46 | 5.44 | 0.21 | 32.1 |
| SG6028H12-HH | 12 | 7.0 to 13.5 | 0.08 | 0.96 | ||||||
| SG6028H24-HH | 24 | 18 to 26.5 | 0.04 | 0.96 | ||||||
