Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SG7525L12 | 12 | 7.0 to 13.5 | 0.11 | 1.32 | 2000 | 0.15 | 5.17 | 2.45 | 0.10 | 25.6 |
| SG7525L24 | 24 | 18 to 26.5 | 0.08 | 1.92 | ||||||
| SG7525M12 | 12 | 7.0 to 13.5 | 0.22 | 2.64 | 2500 | 0.19 | 6.74 | 4.58 | 0.18 | 32.3 |
| SG7525M24 | 24 | 18 to 26.5 | 0.11 | 2.64 | ||||||
| SG7525H12 | 12 | 7.0 to 13.5 | 0.26 | 3.12 | 3000 | 0.23 | 8.18 | 7.29 | 0.29 | 37.6 |
| SG7525H24 | 24 | 18 to 26.5 | 0.14 | 3.36 | ||||||
| SG7525H12-HH | 12 | 7.0 to 13.5 | 0.42 | 5.04 | 3500 | 0.27 | 9.52 | 10.98 | 0.43 | 41.6 |
| SG7525H24-HH | 24 | 18 to 26.5 | 0.23 | 5.52 | ||||||
