Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP12025H12 | 12 | 8.0 to 13.5 | 0.55 | 6.6 | 3500 | 2.82 | 99.72 | 10.65 | 0.42 | 53 |
| SP12025H24 | 24 | 18 to 26.5 | 0.30 | 7.2 | ||||||
| SP12025H48 | 48 | 36 to 54 | 0.15 | 7.2 | ||||||
| SP12025H12-HH | 12 | 8.0 to 13.5 | 0.70 | 8.4 | 4000 | 3.18 | 112.31 | 13.34 | 0.53 | 56 |
| SP12025H24-HH | 24 | 18 to 26.5 | 0.36 | 8.64 | ||||||
| SP12025H48-HH | 48 | 36 to 54 | 0.17 | 8.16 | ||||||
| SP12025H12-VH | 12 | 8.0 to 13.5 | 0.90 | 10.8 | 4500 | 3.59 | 126.81 | 16.68 | 0.66 | 60 |
| SP12025H24-VH | 24 | 18 to 26.5 | 0.46 | 11.04 | ||||||
| SP12025H48-VH | 48 | 36 to 54 | 0.23 | 11.04 | ||||||
| SP12025H12-SH | 12 | 8.0 to 13.5 | 1.35 | 16.2 | 5500 | 4.43 | 156.41 | 24.61 | 0.97 | 65 |
| SP12025H24-SH | 24 | 18 to 26.5 | 0.68 | 16.32 | ||||||
| SP12025H48-SH | 48 | 36 to 54 | 0.34 | 16.32 | ||||||
| SP12025H12-EH | 12 | 8.0 to 13.5 | 2.3 | 27.6 | 6500 | 5.34 | 188.48 | 31.9 | 1.26 | 69 |
| SP12025H24-EH | 24 | 18 to 26.5 | 1.1 | 26.4 | ||||||
| SP12025H48-EH | 48 | 36 to 54 | 0.55 | 26.4 | ||||||
