Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP12025L12 | 12 | 8.0 to 13.5 | 0.32 | 3.84 | 3000 | 3.18 | 112.2 | 6.48 | 0.26 | 44.5 |
| SP12025L24 | 24 | 18 to 26.5 | 0.16 | 3.84 | ||||||
| SP12025L48 | 48 | 36 to 54 | 0.09 | 4.32 | ||||||
| SP12025M12 | 12 | 5.0 to 13.5 | 0.78 | 9.36 | 3500 | 3.85 | 135.7 | 9.70 | 0.38 | 48.6 |
| SP12025M24 | 24 | 18 to 26.5 | 0.36 | 8.64 | ||||||
| SP12025M48 | 48 | 36 to 54 | 0.18 | 8.64 | ||||||
| SP12025H12 | 12 | 5.0 to 13.5 | 1.00 | 12.0 | 3800 | 4.22 | 149.0 | 10.9 | 0.43 | 52.3 |
| SP12025H24 | 24 | 18 to 26.5 | 0.50 | 12.0 | ||||||
| SP12025H48 | 48 | 36 to 54 | 0.26 | 12.48 | ||||||
