Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP12032L12 | 12 | 8.0 to 13.5 | 0.35 | 4.20 | 2000 | 2.35 | 82.85 | 4.16 | 0.16 | 40 |
| SP12032L24 | 24 | 18 to 26.5 | 0.18 | 4.32 | ||||||
| SP12032L48 | 48 | 36 to 54 | 0.09 | 4.32 | ||||||
| SP12032M12 | 12 | 8.0 to 13.5 | 0.55 | 6.6 | 2500 | 2.92 | 103.04 | 6.48 | 0.26 | 47.2 |
| SP12032M24 | 24 | 18 to 26.5 | 0.26 | 6.24 | ||||||
| SP12032M48 | 48 | 36 to 54 | 0.12 | 5.76 | ||||||
| SP12032H12 | 12 | 8.0 to 13.5 | 0.82 | 9.84 | 3000 | 3.55 | 125.41 | 9.15 | 0.36 | 52.4 |
| SP12032H24 | 24 | 18 to 26.5 | 0.42 | 10.08 | ||||||
| SP12032H48 | 48 | 36 to 54 | 0.21 | 10.08 | ||||||
| SP12032H12-HH | 12 | 8.0 to 13.5 | 1.15 | 13.8 | 3500 | 4.23 | 149.37 | 12.86 | 0.51 | 56.8 |
| SP12032H24-HH | 24 | 18 to 26.5 | 0.60 | 14.4 | ||||||
| SP12032H48-HH | 48 | 36 to 54 | 0.29 | 13.92 | ||||||
| SP12032H12-VH | 12 | 8.0 to 13.5 | 1.6 | 19.2 | 4000 | 4.89 | 172.57 | 16.53 | 0.65 | 60.3 |
| SP12032H24-VH | 24 | 18 to 26.5 | 0.81 | 19.44 | ||||||
| SP12032H48-VH | 48 | 36 to 54 | 0.41 | 19.68 | ||||||
