Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP12038L12 | 12 | 8.0 to 13.5 | 0.90 | 10.8 | 5500 | 4.55 | 160.6 | 38.68 | 1.53 | 60.7 |
| SP12038L24 | 24 | 18 to 26.5 | 0.45 | 10.8 | ||||||
| SP12038L48 | 48 | 36 to 54 | 0.25 | 12.0 | ||||||
| SP12038M12 | 12 | 8.0 to 13.5 | 1.70 | 20.4 | 6500 | 5.42 | 191.2 | 49.06 | 1.93 | 65.0 |
| SP12038M24 | 24 | 18 to 26.5 | 0.85 | 20.4 | ||||||
| SP12038M48 | 48 | 36 to 54 | 0.43 | 20.64 | ||||||
| SP12038H12 | 12 | 8.0 to 13.5 | 2.80 | 33.6 | 7800 | 6.48 | 228.6 | 54.94 | 2.16 | 68.7 |
| SP12038H24 | 24 | 18 to 26.5 | 1.50 | 36.0 | ||||||
| SP12038H48 | 48 | 36 to 54 | 0.75 | 36.0 | ||||||
