Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP13050L12 | 12 | 8.0 to 13.5 | 0.16 | 1.92 | 1500 | 1.03 | 36.40 | 3.40 | 0.13 | 23.6 |
| SP13050L24 | 24 | 18 to 26.5 | 0.08 | 1.92 | ||||||
| SP13050L48 | 48 | 36 to 54 | 0.04 | 1.92 | ||||||
| SP13050M12 | 12 | 8.0 to 13.5 | 0.33 | 3.96 | 2000 | 1.39 | 48.93 | 4.35 | 0.17 | 28.7 |
| SP13050M24 | 24 | 18 to 26.5 | 0.16 | 3.74 | ||||||
| SP13050M48 | 48 | 36 to 54 | 0.07 | 3.56 | ||||||
| SP13050H12 | 12 | 8.0 to 13.5 | 0.55 | 6.6 | 2500 | 1.78 | 62.6 | 5.48 | 0.22 | 33.6 |
| SP13050H24 | 24 | 18 to 26.5 | 0.26 | 6.24 | ||||||
| SP13050H48 | 48 | 36 to 54 | 0.12 | 5.76 | ||||||
| SP13050H12-HH | 12 | 8.0 to 13.5 | 0.94 | 11.28 | 3000 | 2.18 | 76.85 | 6.85 | 0.27 | 41.8 |
| SP13050H24-HH | 24 | 18 to 26.5 | 0.45 | 10.8 | ||||||
| SP13050H48-HH | 48 | 36 to 54 | 0.21 | 10.18 | ||||||
| SP13050H12-VH | 12 | 8.0 to 13.5 | 1.03 | 12.36 | 3200 | 2.28 | 80.4 | 7.3 | 0.29 | 43.51 |
| SP13050H24-VH | 24 | 18 to 26.5 | 0.49 | 11.76 | ||||||
| SP13050H48-VH | 48 | 36 to 54 | 0.23 | 11.14 | ||||||
