Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP14038L12 | 12 | 8.0 to 13.5 | 1.20 | 14.4 | 4500 | 5.06 | 178.5 | 29.65 | 1.17 | 62.3 |
| SP14038L24 | 24 | 18 to 26.5 | 0.63 | 15.1 | ||||||
| SP14038L48 | 48 | 36 to 54 | 0.32 | 15.4 | ||||||
| SP14038L12 | 12 | 8.0 to 13.5 | 3.30 | 39.6 | 6800 | 8.23 | 297.3 | 62.43 | 2.46 | 69.1 |
| SP14038L24 | 24 | 18 to 26.5 | 1.65 | 39.6 | ||||||
| SP14038L48 | 48 | 36 to 54 | 0.90 | 43.2 | ||||||
| SP14038L12 | 12 | 8.0 to 13.5 | 5.40 | 64.8 | 8200 | 10.17 | 358.8 | 78.84 | 3.11 | 76.9 |
| SP14038L24 | 24 | 18 to 26.5 | 2.72 | 65.3 | ||||||
| SP14038L48 | 48 | 36 to 54 | 1.38 | 66.3 | ||||||
