Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP6015L05 | 5 | 3.6 to 6.8 | 0.35 | 1.65 | 4000 | 0.42 | 15.09 | 3.38 | 0.14 | 32.2 |
| SP6015L12 | 12 | 7.0 to 13.5 | 0.15 | 1.60 | ||||||
| SP6015M12 | 12 | 7.0 to 13.5 | 0.20 | 2.40 | 5000 | 0.55 | 19.56 | 5.23 | 0.21 | 36.0 |
| SP6015M24 | 24 | 18 to 26.5 | 0.10 | 2.40 | ||||||
| SP6015H12 | 12 | 7.0 to 13.5 | 0.26 | 3.12 | 6000 | 0.71 | 25.0 | 7.33 | 0.29 | 45.0 |
| SP6015H24 | 24 | 18 to 26.5 | 0.13 | 3.12 | ||||||
