Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP7010L05 | 5 | 3.6 to 6.8 | 0.21 | 1.05 | 2000 | 0.29 | 10.31 | 0.9 | 0.03 | 23.4 |
| SP7010L12 | 12 | 7.0 to 13.5 | 0.10 | 1.20 | ||||||
| SP7010L24 | 24 | 18 to 26.5 | 0.05 | 1.20 | ||||||
| SP7010M05 | 5 | 3.6 to 6.8 | 0.33 | 1.65 | 2500 | 0.42 | 14.71 | 1.55 | 0.06 | 27.2 |
| SP7010M12 | 12 | 7.0 to 13.5 | 0.14 | 1.68 | ||||||
| SP7010M24 | 24 | 18 to 26.5 | 0.07 | 1.68 | ||||||
| SP7010H12 | 12 | 7.0 to 13.5 | 0.20 | 2.40 | 3000 | 0.52 | 18.46 | 2.07 | 0.08 | 30.9 |
| SP7010H24 | 24 | 18 to 26.5 | 0.10 | 2.40 | ||||||
