Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
| ◯ | ◯ |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| ◯ | ◯ | ◯ | ◯ |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP7015L05 | 5 | 3.6 to 6.8 | 0.20 | 1.0 | 3500 | 0.64 | 22.52 | 2.91 | 0.11 | 33.5 |
| SP7015L12 | 12 | 7.0 to 13.5 | 0.08 | 0.96 | ||||||
| SP7015L24 | 24 | 18 to 26.5 | 0.04 | 0.96 | ||||||
| SP7015M12 | 12 | 7.0 to 13.5 | 0.12 | 1.44 | 4000 | 0.70 | 24.65 | 3.69 | 0.15 | 35.3 |
| SP7015M24 | 24 | 18 to 26.5 | 0.06 | 1.44 | ||||||
| SP7015H12 | 12 | 7.0 to 13.5 | 0.17 | 2.04 | 4500 | 0.82 | 28.97 | 4.66 | 0.18 | 40.5 |
| SP7015H24 | 24 | 18 to 26.5 | 0.09 | 2.16 | ||||||
