Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP7020L12 | 12 | 7.0 to 13.5 | 0.12 | 1.44 | 2500 | 0.60 | 21.36 | 1.91 | 0.08 | 26.3 |
| SP7020L24 | 24 | 18 to 26.5 | 0.06 | 1.44 | ||||||
| SP7020M12 | 12 | 7.0 to 13.5 | 0.2 | 2.4 | 3000 | 0.72 | 25.26 | 2.74 | 0.11 | 33.6 |
| SP7020M24 | 24 | 18 to 26.5 | 0.11 | 2.64 | ||||||
| SP7020H12 | 12 | 7.0 to 13.5 | 0.24 | 2.88 | 3500 | 0.84 | 29.55 | 3.81 | 0.15 | 38.8 |
| SP7020H24 | 24 | 18 to 26.5 | 0.13 | 3.12 | ||||||
| SP7020H12-HH | 12 | 7.0 to 13.5 | 0.34 | 4.08 | 4000 | 0.97 | 34.15 | 4.97 | 0.20 | 40.6 |
| SP7020H24-HH | 24 | 18 to 26.5 | 0.17 | 4.08 | ||||||
| SP7020H12-VH | 12 | 7.0 to 13.5 | 0.44 | 5.28 | 4500 | 1.06 | 37.39 | 6.11 | 0.24 | 42.2 |
| SP7020H24-VH | 24 | 18 to 26.5 | 0.22 | 5.28 | ||||||
| SP7020H12-SH | 12 | 7.0 to 13.5 | 0.48 | 5.76 | 5000 | 1.19 | 42.09 | 7.71 | 0.30 | 44.3 |
| SP7020H24-SH | 24 | 18 to 26.5 | 0.24 | 5.76 | ||||||
