Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP8020L12 | 12 | 7.0 to 13.5 | 0.11 | 1.32 | 2500 | 0.61 | 21.7 | 2.01 | 0.08 | 28 |
| SP8020L24 | 24 | 18 to 26.5 | 0.07 | 1.68 | ||||||
| SP8020M12 | 12 | 7.0 to 13.5 | 0.19 | 2.28 | 3500 | 0.87 | 30.62 | 3.72 | 0.15 | 38 |
| SP8020M24 | 24 | 18 to 26.5 | 0.12 | 2.88 | ||||||
| SP8020H12 | 12 | 7.0 to 13.5 | 0.33 | 3.96 | 4500 | 1.11 | 39.19 | 5.8 | 0.23 | 44.5 |
| SP8020H24 | 24 | 18 to 26.5 | 0.17 | 4.08 | ||||||
| SP8020H48 | 48 | 36 to 54 | 0.08 | 3.84 | ||||||
| SP8020H24-HH | 24 | 18 to 26.5 | 0.24 | 5.76 | 5000 | 1.21 | 42.67 | 6.61 | 0.26 | 47.2 |
| SP8020H48-HH | 48 | 36 to 54 | 0.12 | 5.76 | ||||||
