Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP9225L12 | 12 | 7.0 to 13.5 | 0.07 | 0.84 | 2000 | 0.91 | 32.29 | 1.97 | 0.08 | 26 |
| SP9225L24 | 24 | 18 to 26.5 | 0.05 | 1.20 | ||||||
| SP9225M12 | 12 | 7.0 to 13.5 | 0.1 | 1.20 | ||||||
| SP9225M24 | 24 | 18 to 26.5 | 0.06 | 1.44 | 2500 | 1.17 | 41.34 | 3.12 | 0.12 | 33.2 |
| SP9225M48 | 48 | 36 to 54 | 0.04 | 1.92 | ||||||
| SP9225H12 | 12 | 7.0 to 13.5 | 0.23 | 2.76 | ||||||
| SP9225H24 | 24 | 18 to 26.5 | 0.13 | 3.12 | 3500 | 1.65 | 58.11 | 5.58 | 0.22 | 42.6 |
| SP9225H48 | 48 | 36 to 54 | 0.06 | 2.88 | ||||||
| SP9225H24-HH | 24 | 18 to 26.5 | 0.20 | 4.8 | ||||||
| SP9225H48-HH | 48 | 36 to 54 | 0.11 | 5.28 | 4500 | 2.08 | 73.55 | 8.57 | 0.34 | 49 |
