Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m³/min | CFM | mmH2O | INH2O | DB-A |
| SP7532L12 | 12 | 7.0 to 13.5 | 0.76 | 9.12 | 3500 | 0.55 | 19.1 | 15.9 | 0.69 | 45 |
| SP7532L24 | 24 | 18 to 26.5 | 0.37 | 8.88 | ||||||
| SP7532L48 | 48 | 36 to 54 | 0.19 | 9.12 | ||||||
| SP7532M12 | 12 | 7.0 to 13.5 | 0.98 | 11.76 | 4500 | 0.72 | 24.54 | 20.45 | 0.89 | 49 |
| SP7532M24 | 24 | 18 to 26.5 | 0.47 | 11.38 | ||||||
| SP7532M48 | 48 | 36 to 54 | 0.25 | 11.70 | ||||||
| SP7532H12 | 12 | 7.0 to 13.5 | 1.2 | 14.4 | 5500 | 0.87 | 30 | 25 | 1.09 | 56.8 |
| SP7532H24 | 24 | 18 to 26.5 | 0.58 | 13.92 | ||||||
| SP7532H48 | 48 | 36 to 54 | 0.3 | 14.4 | ||||||
