Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | CMH | CFM | mmH2O | INH2O | DB-A |
| SD250H24 | 24 | 18 to 26.5 | 6.1 | 146.4 | 2800 | 1218.1 | 716.5 | 85.5 | 3.4 | 76 |
| SD250H48 | 48 | 36 to 54 | 3.1 | 148.8 | ||||||
