Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | CMH | CFM | mmH2O | INH2O | DB-A |
| SD280H24 | 24 | 18 to 26.5 | 6.2 | 148.8 | 2200 | 1491.6 | 877.4 | 47.6 | 1.88 | 73.0 |
| SD280H48 | 48 | 36 to 54 | 3.0 | 144 | ||||||
