Description
Available Functions
Motor Protection
| RP | SS | LP | CL | OVP |
| ◯ | ◯ |
Signal Output
| FG | RD | RDB | LD |
Speed Control Mode
| PWM | TC | VC | CC | CS |
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | VAC | VAC | Hz | Watt | R.P.M | CMH | CFM | mmH2O | INH2O | DB-A |
| SDE220H110 | 110 | 80 to 135 | 50/60 | 60 | 2650 | 855.6 | 503.3 | 43.15 | 1.7 | 70.5 |
| SDE220H220 | 220 | 180 to 265 | 50/60 | 60 | ||||||
| SDE220H110 | 110 | 80 to 135 | 50/60 | 150 | 3200 | 1111.5 | 653.9 | 60.5 | 2.38 | 72.0 |
| SDE220H220 | 220 | 180 to 265 | 50/60 | 150 | ||||||
